Progressive Die Stamping Services
Complex parts demand speed, precision, and repeatability. Our progressive die stamping process is built to deliver all three and drive better efficiency and ROI across your program.
IATF 16949:2016 Certified | ISO 9001:2015 Certified
What is Progressive Die Stamping?
Progressive die stamping is a metal forming process in which a metal strip is fed through a series of die stations in a single press, with each station performing a different operation — blanking, piercing, bending, forming, or coining — until a finished or near-finished part exits at the end. Because multiple operations are completed in a single machine setup without repositioning or transferring the part, progressive die stamping is faster, more accurate, and more repeatable than single-stage stamping alternatives.
Progressive Die Stamping Services
Here’s what you can expect when you trust your progressive die stampings to LMC.
Production Speed
Because several operations are performed in a single press, complex parts can be produced more quickly using progressive die stamping. The progressive die stamping process is also faster because it only requires a single setup.
Precision and Repeatability
Because the material is continuously fed into the machine and doesn’t require repositioning or transferring to another press during production, progressive die stamping is a highly repeatable and accurate process.
Efficiency for Complex Parts
Because the production run can be supervised by a single operator, progressive die stamping is cost-efficient. The process also leaves behind minimal scrap, which benefits the environment and your bottom line.
You can simplify your supply chain and reap the benefits of quality results when you trust your progressive die stampings and secondary processing to LMC.
Tool & Die Support
Progressive die stamping often requires complex tooling. We assess, repair, and maintain your progressive dies so you get the maximum life from your tooling.
Learn MorePlastic Overmolding
You can have your progressive stampings turned into finished parts right in our facility, saving you valuable time and transportation costs.
Learn MorePlastic Injection Molding
Have a diversified product mix that includes injection molded parts? We can help.
Learn MoreIndustries Served
Progressive die stamping helps bring all types of intricate products to life in markets such as automotive, consumer products, electronics, and medical devices. Visit our Industries pages to learn more about how we tailor our approach to serve your unique sector.
Certifications and Approvals
Frequently Asked Questions
Both progressive die stamping and transfer die stamping use multiple die stations to produce finished metal parts, but they differ in how the part moves through the press. In progressive die stamping, the metal remains attached to a carrier strip as it advances through each station. The strip feeds continuously through the press and the part is cut free only at the final station. This makes progressive die stamping faster, more automated, and better suited for smaller, higher-volume parts that can be produced from coil stock.
In transfer die stamping, the part is separated from the strip early in the process and physically transferred from station to station by mechanical fingers or a robotic system. This makes transfer stamping better suited for larger parts or complex geometries that require more freedom of movement between operations, such as deep drawn parts or parts requiring forming from multiple directions.
Progressive die stamping generally offers lower tooling and operating costs for high-volume runs, while transfer die stamping provides greater flexibility for larger or more complex part geometries.
Progressive die tooling is a significant upfront investment, and cost varies widely depending on part complexity, the number of die stations required, tolerances, and the materials used to build the tool. A simple progressive die for a straightforward stamped component might start in the range of $10,000 to $30,000, while complex multi-station progressive dies for tight-tolerance automotive or medical components can range from $50,000 to $150,000 or more. The investment is substantial, but it amortizes rapidly across high-volume production runs.
Progressive die stamping is best suited for parts that are relatively flat or moderately formed, produced from coil or strip stock, and required in high volumes with consistent, tight tolerances. Ideal candidates include stamped metal brackets, contacts, terminals, clips, connectors, shields, and structural components that require multiple punching, bending, or forming operations.
Tooling quality is one of the most significant factors in progressive die stamping performance. It directly affects part accuracy, consistency, scrap rates, cycle times, and the total cost of your program over time.
A well-designed and well-maintained progressive die produces parts that consistently hit tolerance, minimizes burrs and defects, runs efficiently with minimal downtime, and holds up across millions of cycles. Poor tooling quality, whether from inadequate design, inferior materials, or insufficient maintenance, leads to dimensional drift, increased scrap, flash and burr issues, unplanned downtime for emergency repairs, and ultimately higher total costs.
Die wear is an inevitable reality in stamping, but its impact can be managed significantly through proactive maintenance programs, regular inspections, and timely replacement of consumable components.
